NBF-22 Hot Water Circulator Pump, 1/25 HP 115V 60Hz, Compatible with Bell & Gossett 103252LF Lead-Free Bronze Recirculating Pump, for Potable Water/Nbf and SSF
Product details
| Management number | 210144980 | Release Date | 2026/04/02 | List Price | $144.00 | Model Number | 210144980 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
More DetailsNBF-22 Hot Water Circulator Pump, 1/25 HP 115V 60Hz, Compatible with Bell & Gossett 103252LF Lead-Free Bronze Recirculating Pump, for Potable Water/Nbf and SSFSpecificationPart Type: Hot Water Circulator Pump Replacement Part Numbers: 103252LF NBF-22Fitment: Compatible with Bell & Gossett NBF-22 Hot Water Recirculating Pump Material: BronzeExterior: PaintedColor: YellowPackage included1 * NBF-22 Hot Water Circulator Pump kit ( As Pictures Shown )NotePlease confirm the part number and compatible fitment information before purchasing.
- Fitment: Replace part number: 103252LF; The 103252LF hot water recirculating pump is compatible with Bell & Gossett NBF-22.
- Specification: ①.Voltage: 115V ②.Frequency: 60 Hz ③.Horse Power: 1/25 HP ④.Flow Range: 0–22 GPM ⑤.Max Head: 15 ft ⑥.Pressure Rating: 150 PSI ⑦.Max Temperature: 230 °F ⑧.RPM: 2940 ⑨. Phase: Single (1) ⑩.Connection Size: 1-1/4", 1-1/2", 3/4" ⑪. Material: Lead-free bronze ⑫.Connection Type: Flanged x Flanged.
- Application: The NBF-22 circulator pump is designed for hot water recirculation, floor radiant heating, solar heating, and plumbing systems in residential and light commercial settings.
- Premium Performance: The recirculation pump features a cast bronze housing for extended service life and is whisper-quiet and rock-solid.
- Note: Please confirm the replace part number and compare old part before purchase. If you have any question, pls feel free to ask us.
| Color | Yellow |
|---|---|
| Voltage | 115 Volts |
| Flow Rate | 22 Gallons Per Minute |
| Brand Name | MINJIANG |
| Unit Count | 1.0 Count |
| Manufacturer | MINJIANG |
| Model Number | 103252LF NBF-22 |
| Power Source | AC |
| Material Type | Bronze |
| Product Style | NBF-22 |
| Included Components | Water Circulator Pump |
